3-12 Chapter 3

3-5. Integrated Peripherals

OnChip IDE Device:
Click <Enter> key to enter its submenu:
IDE HDD Block Mode:
This item determines to use the Block Mode for IDE HDD.
[Enabled]: The IDE HDD supports block mode.
[Disabled]: The IDE HDD supports standard mode.
OnChip IDE-1 Controller:
This item allows you to enable or disable the primary and secondary IDE controller. Select [Disabled] if
you want to add a different hard drive controller.
Master/Slave Drive PIO Mode
The PIO (Programmed Input/Output) mode allows the BIOS to tell the controller what it wants and then
let the controller and the CPU perform the complete task, rather than having the BIOS issue a series of
commands to affect a transfer to or from the disk drive.
[Auto]: The BIOS will select the best available mode after checking your disk drive.
IC7-G
