[Mode 0-4]: You can select a mode that matches your disk drive's timing. Do not use the wrong setting
or you will have drive errors.
Master/Slave Drive Ultra DMA
This item allows you to set the Ultra DMA in use.
[Auto]: The BIOS will select the best available option after checking your hard drive or CD-ROM.
[Disabled]: The BIOS will not detect these categories. If problem arises in using Ultra DMA devices, try
disabling this item.
OnChip IDE-2 Controller:
The description is same as the OnChip IDE-1 Controller.
OnChip Serial ATA:
This option enables or disables the SATA controller of ICH5R South Bridge.
Serial ATA 1 Mode / Serial ATA 2 Mode:
This item determines the function mode for Serial ATA Port 1 (i.e. The SATA1 connector in this model)
and Serial ATA Port 2 (i.e. The SATA2 connector in this model). Both SATA1 and SATA2 will be
served each as one single IDE connector after selected as the following modes:
Serial ATA Port 1
(SATA1)
Mode 1 IDE-1 Master
Mode 2 IDE-1 Slave
Mode 3 IDE-2 Master
Mode 4 IDE-2 Slave
Mode 5 Logical IDE-1
Mode 6 Logical IDE-2
Mode 7 IDE-3 Master
Mode 8 IDE-4 Master
Serial ATA Port 2
(SATA2)
IDE-1 Slave
IDE-1 Master
IDE-2 Slave
IDE-2 Master
Logical IDE-2
Logical IDE-1
IDE-4 Master
IDE-3 Master
Description
• SATA1 serves as IDE-1 Master
• SATA2 serves as IDE-1 Slave
• OnChip IDE-1 controller disabled
• SATA1 serves as IDE-1 Slave
• SATA2 serves as IDE-1 Master
• OnChip IDE-1 controller disabled
• SATA1 serves as IDE-2 Master
• SATA2 serves as IDE-2 Slave
• OnChip IDE-2 controller disabled
• SATA1 serves as IDE-2 Slave
• SATA2 serves as IDE-2 Master
• OnChip IDE-2 controller disabled
• SATA1 serves as IDE-1
• SATA2 serves as IDE-2
• OnChip IDE-1 and IDE-2 controller disabled
• SATA1 serves as IDE-2
• SATA2 serves as IDE-1
• OnChip IDE-1 and IDE-2 controller disabled
• SATA1 serves as IDE-3 Master
• SATA2 serves as IDE-4 Master
• OnChip IDE-1 and IDE-2 controller enabled
• SATA1 serves as IDE-4 Master
• SATA2 serves as IDE-3 Master
• OnChip IDE-1 and IDE-2 controller enabled
