PRODUCT DESCRIPTION
If two values are specified, they are related to each
other, e.g.:
• S3 5 min/20 min
Operation 5 min / standstill 15 min
• S3 25 %/20 min
Operation 5 min / standstill 15 min

3.5. Technical data

General data
Line power [V/F]:
Power consumption [P ]:
1
Rated motor power [P ]:
2
Maximum delivery head [H]:
Maximum volume flow [Q]:
Activation type [AT]:
Fluid temperature [t]:
Protection class:
Insulation class [Cl.]:
Speed [n]:
Max. immersion depth:
Explosion protection:
Operating modes
Immersed [OT ]:
S
Non-immersed [OT ]:
E
Switching frequency
Recommended:
Maximum:
Free ball passage
PRO V05-...:
PRO V06-...:
PRO V08-...:
Suction connection:
PRO ...05-...:
PRO ...06-...:
PRO ...08-...:
Pressure connection:
PRO ...05-...:
PRO ...06-...:
PRO ...08-...:
* S1 operation when non-immersed is not possible
with all motors. Observe the information on the
rating plate.
** Operating mode S3 50% is permissible if the
necessary motor cooling is guaranteed by complete
immersion for at least 1 minute before the motor is
switched back on again.
Installation and operating instructions Wilo-Rexa PRO
See rating plate
See rating plate
See rating plate
See rating plate
See rating plate
See rating plate
37..104 °F (3...40 °C)
IP 68
F (optionally H)
See rating plate
66 ft (20 m)
FM
S1
S1*, S2 30min, S3 25%**
20 /h
50 /h
2.0 in (50 mm)
2.5 in (65 mm)
3.0 in (80 mm)
DN 50/PN 10
DN 65/PN 10
DN 80/PN 10
ANSI B16.1 125lbs 2/Npt2
ANSI B16.1 125lbs 2.5/3
ANSI B16.1 125lbs 3
The specified technical data apply to the standard
pumps in the PRO series.
The technical data for freely configured pumps in
the PRO series can be found in the relevant order
confirmation.

3.6. Type key

Wilo-Rexa
Example:
PRO V06DA-110/EAD1F2-T0015-646-O
PRO Series
Impeller shape
V V = vortex impeller
C = single-channel impeller
Pressure connection size
05 = ANSI B16.1 125lbs 2/Npt2
06
06 = ANSI B16.1 125lbs 2.5/3
08 = ANSI B16.1 125lbs 3
Hydraulic version
D = suction side drilled acc. to DIN
D
N = suction side drilled acc. to North American
Standard (ANSI)
"Hydraulic" material version
A A = standard version
Y = special version
110
Hydraulics type
Motor version
E E = glanded motor
R = reduced-power glanded motor
"Hydraulic" material version
A
A = standard version
Y = special version
Seal version
D D = 2 independent mechanical seals
B = cartridge seal
IE efficiency class, e.g.: 1 = IE1 (based on
1
IEC 60034-30)
With Ex-rating:
X = ATEX
F
F = FM
C = CSA
2 Number of poles
Line power version
T
M = 1~
T = 3~
0015 /10 = rated power P
Frequency
6 5 = 50 Hz
6 = 60 Hz
46 Key for rated voltage
Additional electrical equipment
O
O = with bare cable end
P = with plug
US English
in kW
