U9C specifications
Nominal (rated) force
General information
Degree of protection
per EN 60529
Spring element
material
Potting material
Cable
Cable length
Weight
9.1 Cable wire assignments, four­wire configuration
Fig. 9.1 Cable diagram
28
F N 50
nom
kN
m
g
Cable shield, connected to the housing
A3815-1.4 HBM: public
100 200
0.5 1
Silicone
Four­wire circuit, PUR insulation
1.5, 3, 7, 12
75
1: White, measurement signal (+)
2: Black, excitation voltage (-)
4: Red, measurement signal (-)
3: Blue, excitation voltage (+)
2 5 10
IP67
Steel
100
20 50
400
U9C
