1.2

Environment Conditions

Devices in explosion-hazard areas are only permitted to operate under following environment
conditions:
• -40 °C
(-40 °F)
• 0.8 bar
(12 psi)
• Air with normal oxygen, typically 21 % (V/V)
In an explosion-hazard area, the EE100Ex may only be powered via intrinsically safe power supply
devices or protective barriers. Even if only the measurement probe is installed in the explosion hazard
area, the EE100Ex must be supplied using intrinsically safe equipment.
The rules for the interconnection of intrinsically safe electrical devices according to EN60079-14,
EN60079-25 and IEC60079-14, IEC60079-25 (proof of intrinsic safety in the system description) as well
as all national requirements shall be observed at all times.
EE100Ex is certified to the standard requirements according to EN60079-11 „ia". Usage is only
permitted in EPL Gb, Zone 1 due to the aluminium enclosure.
Each EE100Ex is provided with its manufacturing date, which is located on the hazard designation label
after the "series" (version), as follows:
CCYYYY: CC
YYYY
1.3

Certifications

EUROPE (ATEX):
The EE100Ex sensor fulfils the ATEX directive 2014/34/EU for intrinsically safe operating equipment
according to the standards:
• EN 60079-0:2012
• EN 60079-11:2012
The EU type approval test has been performed by TÜV SÜD Product Service GmbH.
Certified to EU type approval test TPS 19 ATEX 038892 0008 X
Entity parameters:
Ex-Designation
II 2G Ex ia IIB T4 Gb
INTERNATIONAL (IECEX):
IECEx approval according following standards:
• IEC 60079-0:2011
• IEC 60079-11:2011
The Certificate of Conformity has been issued by TÜV SÜD Product Service GmbH.
Certificate No.: IECEx TPS 18.0014 X
Entity parameters:
Ex-Designation
Ex ia IIB T4 Gb
EE100Ex Safety Guide
≤ T ≤ 60 °C
(140 °F)
≤ p ≤ 1.1 bar
calender week
year
Ui = 28V; Ii = 100mA; Pi: = 700mW; Ci = 2,2nF; Li ≈ 0mH
Ui = 28Vdc; Ii = 100mA; Pi = 700mW; Ci = 2,2nF; Li = 0mH
(16 psi)
5
