8.0.0 TECHNICAL DATA

8.1.0 OPERATING ELEMENT

Connection:
Power consumption:
Ambient conditions:
Housing:
Mounting:
Dimensions USB-dock:

8.2.0 LED POWER ELEMENT

Supply:
Power consumption:
Ambient conditions:
Housing:
Mounting:

8.3.0 LED COLOURED LAMP

Connection:
Power consumption:
Ambient conditions:
Housing:
Mounting:
4-pin with supply and communication lines (3m)
5V= / <100 mA normal operation (<0.5 W)
0° C – 130° C, max. 99 % rel. hum idity, non-
condensing!
Flush-mounted box; board; optical fibre for display;
wooden front with temperature-resistant foil. Board
over M2.5 bolt on wooden front; rear with flush-
mounted box
Fasten to the sauna wall with the screws supplied
L x W x D= 30 x 92 x 9.5 mm
3-pin 230V +/-6%; 50Hz; with protective conductor (PE)
Depending on chroma and brightness max. 50W.
0-50° C, max. 95% rel. h. non-co ndensing
Plastic housing with cover
L x B x H = 243 x 214.5 x 70 mm
Fasten housing with screws to the sauna cabin
At least 5x0.75mm² +;4x0.5 mm² for Audio with 5m
silicone cable
Depending on chroma and brightness max. 50W
Glass surface: max. 130° C outside
Rear: max. 30° C ambient temperature
L x W x D = 780 x 185 x 75 mm
Light-emitting surface = 620 x 150 mm
Size of recess 765 x 158 x 75 mm
With full timber cabins additional frame into the ceiling
element and make the recess larger accordingly.
As per sauna design or with 4 wood screws onto the
sauna ceiling
