4.3.3. REMOTE START ACTIVATE/ DEACTIVATE

In the remote start mode, the coloured lamp switches after connection of the mains voltage to
the last den activated operating mode. (no standby operation) The remote start function is
activated as follows:
4. After setting and confirming the mode (SIN/SAU) by pressing the
key, the remote start setting flashes
(Po0 or Po1)
5. Set the operating mode with the
Po0.......no remote start mode
Po1.......remote start mode active
6. Confirm inputs with
5.0.0 CONNECTION OF SEVERAL sound&light COLOURED
LAMPS
Up to 4 sound&light coloured lamps can be controlled via an operating element. To allow this,
the power elements are connected to each other via a BUS line (RJ12 or RJ11 cable) and
controlled via the LED coloured light operating element. The LED coloured lamps connected to
an operating element can not be individually controlled but only together.
There must be a power element defined to which the operating element is connected and from
which the music data (MP3 or AUX) are given.
This is done via a jumper located on the power element board:
Jumper closed (delivery status)
Power element MASTER
keys.
to save the changes
Jumper open
Power element SLAVE
