Sentiotec WAVE.COM4 SOUND&LIGHT Bedienungsanleitung Seite 23

OPERATING INSTRUCTIONS
LED-Coloured lamp sound&light
Description
Order reference
for company
Author
Version
drafted
CONTENTS
1.0.0 GENERAL
1.1.0 INTRODUCTION
2.0.0 MANUFACTURER'S DECLARATION
3.0.0 FITTING INSTRUCTIONS
3.1.0 DIMENSIONS / FITTING OPERATING ELEMENT + USB DOCK
3.2.0 FITTING THE CONTROL ELEMENT
3.3.0 FITTING THE COLOURED LAMP
3.4.0 CONNECTION DIAGRAM
4.0.0 OPERATING INSTRUCTIONS FOR THE END USER
4.1.0 GENERAL SAFETY NOTICES
4.2.0 OPERATION
4.2.1. FUNCTION DESCRIPTION
4.2.2. OPERATING ELEMENTS
4.2.3. TABLE OF COLOURS
4.2.4. MODES
4.3.0 PROGRAMMING FUNCTIONS
4.3.1. PROGRAMMING CYCLE TIME
4.3.2 PROGRAMMING COLOUR TRANSITION PERIOD
4.3.3 PROGRAMMING COLOURS
4.3.2. MASTER / SLAVE PROGRAMMING
4.3.3. REMOTE START ACTIVATE/ DEACTIVATE
5.0.0 CONNECTION OF SEVERAL sound&light COLOURED LAMPS
6.0.0 CONNECTION TO THE wave.com4 SAUNA CONTROL
7.0.0 FAULTS, CAUSES, SOLUTIONS
8.0.0 TECHNICAL DATA
8.1.0 OPERATING ELEMENT
8.2.0 LED POWER ELEMENT
8.3.0 LED COLOURED LAMP
LED- Coloured lamp sound&light
wave.com4 sound&light coloured lamp set
wave.com4 sound&light operating element
Florian Aichstill
V01
06.2013
23/44
