OPERATING INSTRUCTIONS

3.3.0 FITTING THE COLOURED LAMP

Dimensions
L x W x D = 780 x 185 x 75 mm
light-emitting surface = 620 x 150 mm
Recess size 765 x 158 x 75 mm
~2000 g without cable and loose
Removing the transportation lock
Remove transportation lock from the coloured lamp before using:
Completely unscrew the two set screws on the back side of the housing counter clockwise
with the enclosed socket wrench.
Next insert the two enclosed plastic covers into the vent.
Remove the transportation lock note from the coloured lamp.
Fitting suggestion
Fitting on sauna ceiling not right above the oven (Max. 130° C on the front pain)
Fitting recess 765 x 158 mm; do not enlarge recess, to ensure fitting is water-tight (!).
Rear free for cooling (max. 30° C ambient temperatur e, NB: 80° C housing temperature is
possible)
4 mounting holes are pre-drilled on the front of the coloured lamp
However, depending on the sauna design or the weight of the coloured lamp (approx. 3kg)
further fastening measures (e.g. screws from the front, etc.) may be required
You should also ensure that the coloured lamp is sealed on the sauna ceiling
28/44
