OPERATING INSTRUCTIONS

1.0.0 GENERAL

1.1.0 INTRODUCTION

Welcome to the user manual for the innovative, high-tech coloured lamp sound&light.
This user manual is designed to help you start up the LED coloured lamp and connect it to the
appropriate parts of the sauna control "wave.com4".
You can operate the coloured lamp in 2 connection modes.
a) Single – operating element master - mode
Pure colour led control, no sauna function, can only be operated with one operating element.
Hardware (connected to the bus bar):
one colour operating element and
one or more LED power elements + associated LED coloured lamp
b) Sauna – operating element slave - mode
The colour-led control is integrated into the sauna control and the operating element acts as a
slave here.
Hardware (connected to the bus bar):
Colour operating element
the sauna base section
one or more LED power elements + associated LED coloured lamp
