5.7. Leg supports

The leg supports of the Supine-Bear "Lasse" can be adjusted in various ways such as in general
height, general angle and knee angle.
Pay attention to hazards of jamming and crushing.
General Height adjustment
Loosen wing screw
Adjust the general height of the leg support
Fasten screw
1
1
2

Knee angle adjustment

Loosen wing screw
Adjust the leg support
Fasten screw
1
2
Repeat the steps for adjustment of the other leg support
16
and locking lever
1 2
and locking lever again.
2
3
and both locking lever
1
to the desired position.
3
and both locking lever
2
3
1
at the back.
to the position of the leg.
3
.
2
again.
