WimTec MULTI 2 Montage- Und Bedienungsanleitung Seite 22

EN
MULTI 2
Assembly - 230-V mains version
6
9
!
ATTENTION!
Perform the following steps
in the order indicated!
22 Urinal flush control
7
10
6.
Connect magnetic valve with electronics module.
7.
Connect the power cable with the electronics module and
activate the voltage supply.
8.
Open the integrated stop valve.
9.
If required, change the electronics module with the desired
settings (see p. 19).
10.
Position the front plate - perform function check.
11.
Secure from below with a screw.
WimTec MULTI 2
8
11
