MULTI 2

Technical data

WimTec MULTI 2 – 230 V:
Supply voltage:
Power consumption:
Magnetic valve:
WimTec MULTI 2 – 9 V:
Battery:
Battery service-life:
Magnetic valve:
Further technical data:
Detection range:
Pre-flush:
Main flush:
Stagnation flush:
Flow pressure:
Static pressure:
Flow rate:
Water inlet:
Water outlet:
Material:
Front plate:
16 Urinal flush control
230 V 50 Hz
ca. 3 VA
1/2" 24 V
9-V alkaline 6LR22 or 6LF22, optional 6-V lithium CR-P2
9-V alkaline – approx. 100,000 flushing activations
(max. 2 years)
6-V lithium – approx. 200,000 flushing activations
(max. 4 years)
1/2" 6 V
adjustable from 30 cm to 70 cm
after 1 s to 5 min of non-usage
from 1 s to 15 s
flushing interval: after 24 h of non-usage,
flushing duration: same as main flush
0.08–0.5 MPa (0.8–5 bar)
max. 0.8 MPa (8 bar)
according to EN 15091
R 1/2" IT
R 1/2" OT
plastic
