TRUSST CT-UTVM Kurzanleitung Seite 7

EN
Attaching the Extension Arms to the Arms
Upper Extension Arms
Arms
Lower Extension Arms
If the holes in the arms do not line up with the holes in the back of the
television, attach the extension arms as follows:
1. Attach the upper extension arms to the top of the arms using the enclosed
bolts, lock washers, and hex nuts (Bag 4) through the side holes.
Note: Use 2 hardware assemblies for each upper extension arm.
2. Attach the lower extension arms to the bottom of the arms using the
enclosed bolts, lock washers, and hex nuts (Bag 4) through the side holes.
Note: Use 2 hardware assemblies for each lower extension arm.
Attach all 4 extension arms to the arms in the same manner.
7
CT-UTVM QRG
Attach extension arms
through the side holes
