Wall Mounting
Wall Mount
Built-in Bubble Level
You can mount the TV onto the wall by first attaching the mounting plate to
the wall.
1. On the wall, locate 2 wooden studs within the width of the mounting
plate.
2. Line up and mark one of the top left holes of the mounting plate to the
center of the left wooden stud at the desired height.
3. Drill a pilot hole where you made the top left mark.
4. Drive 1 hex screw (not included) and 1 washer (Bag 6) through the top
left hole in the mounting plate and through the drywall into the center of
the stud.
5. Using the built-in bubble level, adjust the mounting plate until it is level.
6. Mark the desired location for the 3 remaining holes in the center of the 2
studs you identified.
7. Drill pilot holes for the 3 remaining holes.
8. Drive in 3 additional hex screws and washers to secure the mounting
plate.
Attach the mounting plate to at least 2 wooden studs and use all 4
screws when attaching the mounting plate to drywall.
Do not over-tighten.
