Mounting the Television onto the Mounting Plate
Latch Close-up
Views
Unlock Latches
Once you properly attach the arms to the TV and properly mount the
mounting plate to TRUSST® (or other truss), you can then mount the TV
onto TRUSST®.
1. Unlock the arms by pushing up the latch on the arms.
2. Place the arms on the upper lip of the mounting plate.
Note: You might need more than one person to lift the TV.
3. Lock the arms under the bottom lip of the mounting plate by pushing
down the latch on the arms. Do this for both arms.
4. To padlock the TV to the mounting plate, insert a padlock (not included)
into the latch.
Arm
Side View
12
EN
Mounting Plate
Back of TV
