Wall Mounting (cont.)
Concrete Wall 1. On the concrete wall, place the mounting plate at the desired height.
2. Using the built-in bubble level, adjust the mounting plate and mark 6
holes.
3. Place the mounting plate aside and drill 6 holes into the concrete, where
marked, and insert 6 concrete anchors (Bag 6) into the holes.
4. Attach the mounting plate to the concrete wall by driving 6 hex bolts and
washers (Bag 6) through the mounting plate and into each anchor.
Use all 6 bolts when attaching the mounting plate to the concrete wall.
Do not over-tighten.
