Terminal and lead-through data for the AC output power cable
NEW:
Inverter type
PVS800-57-0875kW-B
PVS800-57-1000kW-C
AC output connection specification
NEW:
Voltage
DC input connection data
NEW:
Maximum DC voltage
(U )
max(DC)
Operational DC voltage
range, U
mppt(DC)
Efficiency
NEW):
Maximum efficiency
PVS800-57-0875kW-B
European (EURO-eta)
efficiency
PVS800-57-0875kW-B
PVS800-57-0875kW-B
efficiency
No. of cable lead-throughs Ø60 mm (2.36")
Type -0875kW-B: 350 V AC 3-phase ± 10%
Type -1000kW-C : 400 V AC 3-phase ± 10%
Types -0875kW-B and -1000kW-C: 1100 V DC
Type --0875kW-B: 525...825 V DC
Type -1000kW-C: 600...850 V DC
525 V
98.7
525 V
98.5
100.00
98.00
96.00
94.00
92.00
90.00
88.00
86.00
84.00
82.00
80.00
0 % 25 %
4 x 3
4 x 3
DC voltage
675 V
98.3
DC voltage
675 V
97.8
50 % 75 %
P/P [%]
825 V
97.9
825 V
97.1
525 V
675 V
825 V
100 %
