9 Specifications
GB
Image sensor: . . . . . . . 8.5 mm (
CCD resolution: . . . . . . hor. 795 x vert. 596 pixels
Signal format: . . . . . . . CCIR, PAL
Synchronization: . . . . . internal, hor. 15 625 Hz,
Resolution: . . . . . . . . . 520 lines
Minimum illumination
w/o extended exposure time
(SENSE UP = OFF): 0.05 lux (F 1.2, 5600 K)
w. extended exposure time
(SENSE UP = x64): . 0.001 lux (F1.2, 5600 K)
White balance: . . . . . . . 3200 – 10 000 K
S/N ratio: . . . . . . . . . . . 52 dB (min.)/60 dB (typ.)
All rights reserved by MONACOR
manual may be reproduced in any form or by any means for any commercial use.
38
1
/ ") CCD chip
3
vert. 50 Hz
(AGC = OFF)
® INTERNATIONAL GmbH & Co. KG. No part of this instruction
Dynamic range: . . . . . . 52 dB
Gain control: . . . . . . . . AGC = ON: 0 – 18 dB
Zoom: . . . . . . . . . . . . . max. double zoom
Lens connection: . . . . . CS-mount, C-mount
Gamma correction
factor: . . . . . . . . . . . . . 0,45/1 (selectable)
Ambient temperature: . -10 °C to +50 °C
Power supply: . . . . . . . 12 V
Dimensions
(W x H x D): . . . . . . . . . 51 x 51 x 115 mm
Weight: . . . . . . . . . . . . 325 g
Video output: . . . . . . . . 1 Vpp/75 Ω
Subject to technical modification.
adapter ring is supplied
/350 mA
