GB
Use the keys
tion with "R-Y GAIN" and the blue contribution with
"B-Y GAIN".
To return to the menu OPTION, select the func-
tion "RETURN" and confirm with the key .
8.9.10 POSI/NEGA – representation of a negative image
Via the item "POSI/NEGA" use the keys
select the standard positive (= POSI) and the nega-
tive (= NEGA) representation of the camera picture.
In some cases, a negative representation can be
useful, e. g. for production surveillance or for viewing
film negatives.
8.9.11 H-REV, V-REV – mirroring of the representation
The items "H-REV" and "V-REV" allow horizontal
and vertical mirroring of the camera picture, inde-
pendent of each other. After selecting the corre-
sponding item, use the keys
mirror function ON or OFF.
The mirror functions can be useful e. g. for using
the camera as a rear monitoring system in a vehicle
(H-REV = ON) or for mounting the camera upside-
down (H-REV and V-REV = ON).
To return to the menu OPTION, select the function
"RETURN" and confirm with the key .
36
and to adjust the red contribu-
and to switch the
8.9.12 MASK - masking of picture areas
If surveillance of certain areas of the picture is not
required, up to four masks can be defined. The
masks are grey rectangles of any desired size and
position which cover certain picture sections.
After selecting "MASK A" to "MASK D" with the
keys and
and to
the respective mask is visible (= ON>) or not
(= OFF). If "ON>" is selected, use the key
the submenu for setting a mask:
POSITION>
SIZE>
RETURN
Adjustment of the mask:
1) Select "POSITION>" with the keys
2) Press the key .
3) Move the upper left corner of the rectangle to the
upper left corner of the area to be covered with
the directional keys
possible because the rectangle is too large, for
the time being continue with the steps 4 to 8 for
, use the keys and
** MASK A[/B/C/D] **
, , ,
to adjust if
to call
and .
. If this is not
