Cable connection

1. Connect the WAN-interface of the BIG 10 with the access port of your network opera-
tor, using a UTP (Unshielded Twisted Pair) CAT5 cable or better, to ensure optimal
transmission parameters. The cable contact assignment at the socket can be requested
from your network provider.
2. Link the BIG 10 with the network interface card of the PC. For this, use an Ethernet
cable and connect it to one of the „LAN"-marked RJ45-sockets on the BIG 10 and to
the RJ45-socket of the network interface card (see the related instructions).
3. Finally use the enclosed plug-in power supply module to connect the socket „12V
DC" of the BIG 10 to the electricity network. Do not use any other power supply
module than the one included in delivery. The use of other power supply units will re-
sult in the loss of the CE conformance and exclude any warranty claims.
40
Colour Status Meaning
green OFF WAN link not established
flashing Data-transfer over minimum one SHDSL
ON all PCS member sync; WAN link established
yellow OFF State WAN init done; all links down; all PCS
member sync; state without any interference
ON fastest link PCS sync, still not all members
sync; state with any interference
flashing link-ID (1...4) fastest link G.hs-transfer
(slow) (up to 4 ON-pulses within 2 seconds)
flashing fastest link line probing
(inverse)
blinking fastest link training; „SHDSL Training" status
at 1 Hz
blinking fastest link data mode; „Line Probing" status
at 2 Hz
blinking (re-)init running; „G.hs" status
at 4 Hz
green OFF LAN-port not established
flashing data-transfer over minimum one LAN-port
(inverse)
ON Link established to at least one LAN port
yellow OFF state without any interference
ON state with any interference
blue OFF WLAN deactivated
flashing data transfer via WLAN
(inverse)
ON WLAN activated
yellow OFF state without any interference
blinking after switching-on, until ready-state of WLAN
access point
ON initialization / state with any interference
BIG 10 Router
