BIG 10 Router
Operating Mode
The operating mode offers multiple setting options and can be configured in RT ("remote
terminal" or CPE) or COT ("central office terminal") mode.
EFM G.hs Mode
ITU G.hs according to ITU-T G.994.1 and IEEE802.3ah
PMMS Mode (Line Probing)
Line Probing according to ITU-T G.991.2 (2004)
PMMS Target Margin
Desired Signal Noise Ratio for the PMMS-mode

3.9.2 Status

Line states of all lines are shown. The view can be refreshed manually („Refresh" button) or
automatically pushing the "Auto Refresh" button.
Line state
Down (Idle) / Down (Ready) Link down
PCS Sync
G.hs Line Probing
G.hs Transfer
Data Mode
Data rate
The following data rates (in kbps) depending on the configuration of the COT side can be
achieved with the BIG 10:
Annex Modulation
Annex A/B TC-PAM-16
TC-PAM-16
Annex AF/BG
TC-PAM-32
Loop Attenuation (dB)
Measured loop attenuation in dB; longer loop length results in high loop attenuation.
SNR (dB)
The SNR ("signal noise ratio") is an index of the line quality. The larger the SNR the better is
the line quality. The SNR ranges from -10 dB to 21 dB.

3.9.3 Performance

This view shows actual performance values of all lines.
Time Stamp
Shows the time after activation of the NT function or the elapsed time (24h format) after acti-
vation of the SHDSL line.
Version: 2011/01/19
Bonding Group established
Negotiation of line parameters
Negotiation of line parameters
Line is in Data Mode
1-pair resp. 2-pair resp.
2-wire 4-wire
192... 2304 384... 4608 576... 6912 768... 9216
192... 3840 384... 7680 576...11520 768...15360
768... 5696 1536...11392 2304...17088 3072...22784
3-pair resp. 4-pair resp.
6-wire 8-wire
