3.8.6 Smart Discard

The BIG 10 supports an innovative function to discard packets earlier depending on its priori-
ty. This prevents resource shortages of the QoS queues by packets with lower priority, in case
the bandwidth shaping allows only a low bandwidth for a port.
The "Smart Discard" function can be configured for each port separately. The modes have the
following function:
Mode
Mode 0
Mode 1
Mode 2
Mode 3

3.8.7 Port Security

Port security allows filtering Ethernet frames at a certain LAN port coming from dynamically
learned or statically edited MAC addresses.
Note: The Port Security function is disabled at the relevant ports, in case the MAC-
address filter is inactive and value "0" has been selected for MAC-address limita-
tion.

3.8.8 Statistics

On this page you can get statistical information for each switch port of your BIG 10.

3.8.9 Monitoring

This site allows you to configure, in how far incoming and/or outgoing data traffic of a discre-
tionary LAN Port or resp. WAN Port shall be mirrored to another LAN Port.
3.9

SHDSL

The following pages show the SHDSL configuration and states of the BIG 10.

3.9.1 Config

On this page specific SHDSL parameter can be configured.
58
at load
> 0%
> 0%
> 75%
> 0%
> 50%
> 75%
> 0%
> 25%
> 50%
BIG 10 Router
discarded packets
0%
0%
25%
0%
50%
75%
0%
25%
50%
Version: 2011/01/19
