introduCtion

1.

1.1. What's in the box

▸
IP camera module with quick manual
▸
An extensive manual is provided in the
camera's web frontend (Help), including an
app installation guide
▸
Supplement information "Setting up the
App TC Behnke"
Important: Keep the supplement in a safe
place. Without the supplement information,
you will not be able to activate the app func-
tionality. Keep all passwords in a safe place.
The camera is equipped with special software
to enable smartphone access.

1.2. General Information

Features

The wide angled Behnke IP Camera Module
is a proprietary Behnke development. By
default, it includes the software necessary
to use the app functionality. Using the app
enables you to use your mobile device for
communication with people at your front door
and to also control the door*.
The camera provides video images with HD
resolution of up to 1280 x 720 pixels. The
camera features a large field of view with a
horizontal angular aperture of 180°. Addition-
ally, the camera features IR-LED illumination
for night vision.
www.behnke-online.com
Instructions Behnke IP camera
The video may be transferred to a video
surveillance system via RSTP stream. Motion-
JPEG and H.264 are available as compression
methods.
RTSP stream
rtsp://<user name>:<password>@<IP
address of the Behnke IP camera>:8557/
video.mp4
User name: admin (alternatively: viewer)
Password: admin (alternatively: viewer)
HTTP stream
http://<user name>:<password>@<IP address
of the Behnke IP camera>/bha-api/video.cgi
User name: admin (alternatively: viewer)
Password: admin (alternatively: viewer)
Single image query (JPEG)
http://<user name>:<password>@<IP address
of the Behnke IP camera>/bha-api/image.cgi
User name: admin (alternatively: viewer)
Password: admin (alternatively: viewer)
*
with the cameras 20-/21-/50-2907A-IP,
43-9587A-IP, 50-1204A/-1207A you can only see
the video stream via APP.
GB
Introduction
43
