Mod. Evolution '70 pulsanti
101°C T1/T2/T3 Flashing – T4 Off
103°C T1/T2 Flashing – T3/T4 Off
105°C T1 Flashing – T2/T3/T4 Off
107°C T1/T4 On – T2/T3 Off
109°C T4 On – T1/T2/T3 Off
111°C T3/T4 On – T1/T2 Off
113°C T2/T3/T4 On – T1 Off
115°C T1/T2/T3/T4 On

All LEDs flash three times to indicate the setting has
been successfully saved.
10.6. Reset (factory default settings)

After pressing the T4 key for a few seconds, it will
be possible to reset the machine to the factory
default settings.

Press key T4 again to confirm the operation.

All LEDs flash three times to indicate the setting has
been successfully saved.

11. MAINTENANCE

Maintenance operations are to be performed
with the machine turned OFF and when cold,
with the power supply disconnected from the
mains.
For cleaning do not use any metals or abrasives such as
steel wool, wire brushes, needles, etc., as well as
corrosive or abrasive detergents. Always use a damp
cloth or sponge or one soaked in alcohol.
11.1. Daily

Clean the outer body with a damp cloth or one
soaked in alcohol.

Clean the spout of the steam nozzle.

Clean the spray units and the seals under the casing
of the delivery units using the special brush
supplied.

Rinse the filters and the filter holder with hot water
and a cloth or sponge. Carefully remove any coffee
residues or deposits.

Check and clean the drain pan.
11.2. Periodic cleaning of the machine or after a period
of intense use. In addition to daily cleaning,
perform the following operations:

Immerse the filters and the filter holder in boiling
water for a few minutes to help dissolve coffee
greases and oils, then use a cloth or a sponge to
remove them completely.
C) No hot water or steam delivery:

No water in the reservoir; refill with water.

Repeat the procedure for the programming of
doses described in
section 10.4.
E) Irregular delivery of coffee:

Clean the filter in the filter holder.

The coffee grounds are too fine or too coarse.

Clean the water reservoir taking care to reposition
the rubber tube with the filter until it touches the
bottom of the reservoir.
12. DECOMMISSIONING
12.1. Temporary

Empty the water reservoir and the spill basin.

Close all switches and remove the power plug from
the mains.

Perform the maintenance operations.

Store the machine in a dry environment, protected
from the elements and with limited access (avoid
leaving it in the reach of minors or unfit persons).
12.2. Definitive
Besides carrying out the operations necessary for a
temporary stop, do the following:

Cut the power cable.

Pack the machine in cardboard or other packaging
material and send it to an authorised waste
disposal facility.

13. PROBLEMS AND REMEDIES

In the event the power cable is damaged,
contact an authorised service centre to have it
replaced.
The disposable materials used for processing or
maintenance, if non-biodegradable or are pollutants,
should be placed in separate containers and sent to
special waste disposal centres.
Inspections which can be performed by the user are to
be performed only after the electrical power supply has
been isolated.
A) The machine does not start:

Check that the plug is connected to the mains.

Check that there is power supply available and that
the residual current device is inserted and the main
switch is in the ON position.

Check the condition of the plug and the power
supply cable; if damaged have them replaced by
qualified personnel.
B) No coffee is delivered:

No water in the reservoir; refill with water.

Repeat the procedure for the programming of
doses described in section 10.4.
For any other anomaly or problem not
specified in this manual, remove the power
plug from the mains, do not carry out any direct
repair
or inspection and contact a qualified technical
assistance service centre
