7. Mounting universal box
UnoBean-Step 01468
Turn the table top over and lay on a clean assembly surface
(e.g. protective cover, etc.).
- Position the guide rails
the table top (distance
100/108 mm). Here the openings of the guide rails
point to each other. Screw on each guide rail with
three 3.5x15 mm countersunk-head screws.
(3)
(1)
(5)
(4)
(1) over the predrilled holes in
(2)

from the user side

(4) is
(5)
Secure the rubber stopper 2 with one 4x20 mm Spax
screw in the designated hole in the table top. Slide the
universal box incl. lid (5) from the user side
two guide rails up against the rubber stopper
(1)
It is also possible to combine the universal box
the chair suspension (6) .
(6)
(4)
Model 01468
(4) into the
.
(3)
(5) with
