Operation; Maintenance - Gude BASIC 10T/DTS Originalbetriebsanleitung

Hydraulic equipment
Tightness must be checked for hydraulic hoses and
connections after app. 4 operating hours and tightened if
necessary.
Only for 400 V appliances: The engine rotation direction
(see the arrow on the appliance) must be respected as
running with wrong rotation direction may damage the oil
pump. In such a case, all claims arising from the warranty
will not apply. If necessary, have the rotation direction
changed by reversing the plug polarity. See pic. 6!
Hydraulic oil/tank
Common hydraulic oil (e.g. HLP 46 or oil with the same
viscosity of another manufacturer) may be added to all
splitters. Oil change not necessary.
Bleed the tank every time the appliance is to be used by
unscrewing and re-screwing of the filling screw (pic. 7/A).

Operation

Caution: Make sure wood is cut at right angle if
possible and tightly sits on the splitter table. Sideways-cut
or extremely branchy wood may slide off or bend the
operating arms.
Put the wood to the designated platforms (tables)
(never on the frame) at all times. This may damage the
splitter.
1. Start the engine by pressing the green switch button.
Caution: make sure the engine rotation direction is
appropriate!
2. When the temperature is low, let the splitter run idle
for app. 15 minutes to enable the oil to warm up to an
appropriate temperature.
3. Put the split material on the table and hold it using the
clamping plates on the lever.
4. Splitting will start by pressing both levers down (as soon
as the splitting knife gets into the wood, tip the lever
slightly out while pressing down. This will prevent the
holding sheets (arms) from getting bent.
5. After splitting is finished, lift at least one lever and the
splitter post will automatically go up.
Operating the log splitter by two persons with one holding
the wood and the other pressing the clamping plates is
strictly prohibited.
Transport instructions
Transport
All log splitters have been fitted with big wheels. To transport
the splitter, grab the splitter post handle with one hand and the
handle above the engine by the other hand and tilt slightly the
splitter to you. In this position, the splitter may easily be moved.
To prevent hydraulic oil leak, the splitter must never be
moved when laying.
Lower the splitting knife down to full extent when moving
the appliance.
Residual risks and protective measures
Warning!!!
Putting out of operation, change, blocking, disassembly
changeover or installation of all parts on safety and
protective components of the appliance are strictly
prohibited. It may lead to serious or life-threatening
injuries if not adhered to.
The manufacturer cannot be hold liable for any material
and personal damage arisen as a result of such
negligence.
Any warranty claim towards the manufacturer will not
apply to all the negligence referred to above.
The splitter may only be operated by one person. When
operating the device, remove any wood remains that could
block or negatively affect the safety and operating
elements from around the splitter and the place of your
work.

Maintenance

Do you have any technical questions? A claim? Do you
need spare parts or the Operating Instructions?
You will be helped quickly and without needless bureaucracy
at our webpage www.guede.com in the Services section.
Please help us be able to assist you. To identify your machine
when claimed, we need to know its serial No., order No, and
year of production. All these details can be found on the type
label. Enter the details below for future reference.
Serial No.
Order No.
Year of production:
Tel. +49 (0) 79 04 / 700-360
Fax: +49 (0) 79 04 / 700-51999
Email: support@ts.guede.com
