Area of application
The appliance can only be used for wood processing. The split
material must have the following dimensions:
- Minimum diameter: 120 mm
Maximum diameter: 400 mm
- Wood splitting along fibre is only allowed.
- Risk of getting jammed at branchy wood when splitting.
- Jammed piece of wood is released by tipping on the
wood.
- Cutting the split wood out prohibited!
Electric/hydraulic connection (pic. 7)
Plugging
All splitters are fitted with undervoltage release in the switch in
accordance with provisions of branch professional
organisations "CE", etc. The release prevents automatic
starting of the appliance in case supply is interrupted as a
result of power failure, unintentional unplugging, defective
fuse, etc. The appliance must unconditionally be switched on
again by pressing the green switching button.
Wilful holding or blocking of the switching button with no
directly earthed conductor automatically leads to switch failure.
In this case that can subsequently be identified the guarantee
expires.
• The appliance meets EN 61000-3-11 requirements and is
subject to special connection conditions. That means that
use on optionally selected connection points is
inadmissible.
•
The appliance can lead to occasional voltage fluctuations
under unfavourable power conditions.
• The appliance is only designated to be used for connection
points not exceeding the maximum allowed impedance of
Z = 0,233 Ω.
max
•
As a user, you must make sure your connection point on
which you want to use the appliance meets the above-
mentioned requirements – after agreement with your
electricity supplier if necessary.
Hydraulic equipment
Tightness needs to be checked at hydraulic hoses and
couplings after app. 4 running hours and tighting must be
provided if necessary.
Hydraulic oil/tank
Common hydraulic oil (e.g. HLP 46 or oil of different producer
of identical viscosity) can be filled in all splitters. Oil change is
not necessary.
Vent the tank before each operation by screwing the filling
screw out and in (pic. 7/A).

Operation

Attention: Make sure wood is cut at right angle, if
possible, and seated closely on the splitting table. Cross-
cut or extremely branchy wood can slide or bend the
service arms.
Always put wood on surfaces (tables) designated for
this purpose (never on the frame). That could damage the
splitter.
1. Start the engine by pressing the green switching button.
2. Keep the feeder cable as short as possible at 230 V
models and select as big cross section as possible.
3. When the temperature is low, let the splitter run idle
for app. 15 minutes so that oil warms up to
corresponding temperature.
4. Put the split material on the table and hold it using
clamping plates on the lever.
5. Splitting starts by pressing both levers down (as soon as
the splitting knife enters wood tip the lever slightly out
while pressing it down. This will prevent holding sheets
(arms) from bending).
6. Lift at least one lever after you have finished splitting – the
splitter pillar will automatically go up.
It is strictly prohibited to operate the wood splitter in
two persons with one holding wood and the other one
pressing on the clamping plates. Blocking one lever
(clamping plate) is prohibited, too.

Transport instructions

Transport
All wood splitters are fitted with big wheels. Grasp the handle
on the splitting pillar with one hand and handle above the
engine with the other hand and slightly tilt the splitter to you for
transport purposes. The splitter can effortlessly be moved in
this position.
To prevent hydraulic oil leakage, never transport the splitter
laid down.
Always let the splitting knife go absolutely down for transport.
Residual risks and protective measures
Warning!!!
Taking out of operation, any change, blocking,
disassembly, changeover or assembly of all parts on
safety and protective equipment of the appliance is strictly
prohibited and can have serious consequences, i.e. life
threatening injuries if not observed.
The producer cannot be held liable for material damages
or injuries caused as a result of such negligence.
All guarantee claims towards the producer immediately
expire at each of the above-mentioned negligence.
The splitter can only be operated by one person. Remove
wood remnants that could block or negatively influence
the safety and service elements near the splitter and
workplace during operation.

Maintenance

Do you have any technical questions? A claim? Do you
need spare parts or the Operating Instructions?
You will be helped quickly and without needless bureaucracy
at our webpage www.guede.com in the Services section.
Please help us be able to assist you. To identify your machine
when claimed, we need to know its serial No., order No, and
year of production. All these details can be found on the type
label. Enter the details below for future reference.
Serial No.
Order No.
Year of production:
Tel. +49 (0) 79 04 / 700-360
Fax: +49 (0) 79 04 / 700-51999
Email: support@ts.guede.com
13
