Appliance description (pic. 1)
1. Handle
2. Splitting knife
3. Clamping plate
4. Operating arm
5. Handle cover
6. Table holder (front)
7. Table blocking
8. Splitter table
9. Wheels
10. On/off / outlet
11. Lift adjustment rod
12. Engine
13. Protecting casing
14. Switching cradle (bottom cover)
15. Sheet clutch
16. Turn table lever
17. Turn table
Appliance
Basic 10T/DTS log splitter
Heavy steel design. Splitting knife out of special steel. All steel
parts with high-quality powder paint. Professional hydraulic
pump to be used in difficult conditions. Deep telescopic part
with additional turn table and removable basic table.
Engine with overheating fuse.
Use as designated
The log splitter has been designed to be operated by 1 person.
Two or more persons must never work with the appliance.
The log splitter has exclusively been designed to split wood
along fibres. Installation, maintenance, repair, etc. instructions
must strictly be followed to prevent risks and damage.
When splitting, it is necessary to make sure the split wood is
only fitted on the grooved sheet of the supporting plate or on
the grooved sheet of the splitter table.
The machine cannot be used for works other than for which
the machine has been designed and that are specified in the
Operating Instructions.
Any other use is a use in conflict with the designation. The
manufacturer will not be liable for any consequential damage
and injuries. Please be sure to know that the machine has not
been designed for industrial purposes.

Warranty

The warranty exclusively applies to material or manufacturing
defects. The original proof of purchase with the purchase date
must be submitted when lodging a claim in the warranty period.
The warranty does not include any unauthorised use, e.g.
appliance overloading, violent use, damage by a third party or
foreign item. The failure to follow the Operating Instructions
and assembly instructions and common wear and tear are not
covered by the warranty either.
Technical specifications
Connection:
Engine power:
Engine speed:
Max. splitting force:
Max. splitting lift:
Forward movement speed:
Backward movement speed:
Hydraulic oil tank:
Cut wood length:
Splitter post:
Max. split wood diameter:
Table dimensions:
Weight:
Article No.
400 V~50 Hz
4000 W P1 / S6 40%
1440 rev per min.
10 tons
510 mm
0.03 m per second
0.15 m per second
8 l (oil type: HLP 46)
1350 mm
120 mm x 120 mm
app. 400 mm
app. 380 x 300 mm
177 kg
02040
Safety instructions
General
For safety reasons, safety instructions mentioned in these
Operating Instructions and instructions on the appliance
regarding the operation, maintenance and repairs must be
respected and followed.
Operating personnel
Risks may be associated with using the log splitter.
Therefore, only trained and experienced persons may
handle and work with the appliance. The operator must
wear tight, close-fitting clothing and protective shoes.
Place of work
To ensure safe wood splitting, it is necessary that the place of
work is level and enables stability keeping and sufficient free
movement. All obstacles must be removed from access paths
for carrying the splitter. Appropriate lighting of the place of
work must be provided.
Make sure there are no persons in the place of work
when operating the appliance or, more precisely, they
keep a sufficient safety distance.
Work preparation
Electric current supply must be interrupted by unplugging the
appliance and pressing the red button for repairs or servicing
the log splitter. Interrupting the electric current supply just
by putting the switch to OFF is not enough. GÜDE log
splitters are always supplied with hardened splitting knives.
However, if slight deformation of the knife edge after splitting
wood containing invisible foreign items, e.g. out of concrete,
steel, etc., it must be removed by a file or grinding off. Keeping
the splitting knife sharp at all times increases the operating
power.
TIP: Lubricate the splitting knife with grease from time to
time (for problem wood).
Before the splitter is put into operation for the first
time, it is necessary to check the safety devices (two-lever
operation, in particular).
CAUTION! Before the appliance is to be put into
operation, make sure the splitter table is fitted safely on
the splitter.
Disposal
The disposal instructions are based on icons placed on the
machine or its package. The description of the meanings can
be found in the "Marking" section.
Transport package disposal
The package protects the machine against damage during
transport. Packing materials are usually chosen depending on
their environmental friendliness and disposal method and can
therefore be recycled. Returning the package to material
circulation saves raw materials and reduces waste disposal
costs. Parts of packages (e.g. foils, styropor®) can be
dangerous to children. Risk of suffocation! Keep parts of the
package away from children and dispose them as soon as
possible.
Operator requirements
The operator must carefully read the Operating Instructions
before using the appliance.
Qualification
No special qualification is necessary for using the appliance
apart from detailed instruction by an expert.
Minimum age
The appliance can only be operated by persons over 18 years
of age. An exception includes youngsters operating the
appliance within their professional education to achieve
necessary skills under trainer's supervision.
