English
1.3.2. Positioning on the car seat
(Fig.3-5)
3
Before you place the
®
capsula MN X
installation aids (IH) to the ISOFIX anchors (IA) in your car. Now take the Top Tether (TT) and
put it forward over the seat. Put the child car seat onto the car seat in driving direction.
1.3.3. Installation and fi xing on the car seat with ISOFIX and Top Tether
(Fig. 6-13a)
Figure 6-6b
Turn the ISOFIX (IE) fi xing lever slightly upwards while pulling the two ISOFIX terminals (IK) as far
out as possible. Release the ISOFIX fi xing lever (IE) and make sure that the two terminals do
not slip back again.
Figure 7-8
Now put the two ISOFIX terminals (IK) to the ISOFIX anchors (IA) on the car and click them into
place until you hear a << click >>.
Figure 9a-b
Please check with the help of the marks on BOTH SIDES, if the seat is properly connected with
the two ISOFIX anchors (IA) of the car.
GREEN: the terminal is fi xed CORRECTLY.
RED: the terminal is fi xed NOT CORRECTLY, please correct it!
Only a proper fi xing of BOTH TERMINALS guarantees the provided hold of the seat and the
protection of your child in the car!
Figure 10-12
Now turn the fi xing lever ISOFIX (IE) slightly upwards and push the seat as far as it goes onto
the seat back of the car. Let the ISOFIX arms (IM) click into place with an audible << click >>.
c -capsula.com
5
on the car seat, fasten if necessary the two supplied
Figure 13-13a
Now take the Top Tether (TT) and put it under the head rest along to the appropriate
Top Tether anchor point of the car. This can be found in the instruction manual of the
car. Click the Top Tether into place and pull the belt tightly. Please check again, if the
child car seat is fi xed safely on the seat.
Warning:
3
Only if the with the ISOFIX anchors (IA) is properly installed in the car
®
capsula MN X
the seat can protect your child optimally.
1.4. Fixing with the three-point belt of your car
1.4.1. Conditions
The seat can be used on all licensed seats of your car, which are equipped with a
three-point belt. For maximum protection, use child car seats preferably on the rear
seat. The seat must NOT be fi xed on the rear center seat with lap belt only!
1.4.2. Positioning on the car seat
Now place the 3 on the car seat in driving direction.
®
capsula MN
1.4.3. Installation and fi xing on the car seat
(Fig. 14-19)
The three-point belt of the car consists of 4 parts: the lap belt (W), the diagonal belt (U),
the buckle tongue (V) and the three-point belt buckle (X).
• Tighten the central adjusting belt (G5), so that the child seat belts do not hang down.
c -capsula.com
