Indoor Unit Installation

Indoor Unit Parts
Air flow louver (at air outlet)
Air inlet (with air filter in it)
Air flow louver (at air outlet)
Safety Precautions
WARNING
• Securely install the indoor unit on a
structure that can sustain its weight. If the
structure is too weak, the unit may fall and
cause personal injury, unit and property
damage, or death.
DO NOT install the indoor unit in a
•
bathroom or laundry room as excessive
moisture can short the unit and corrode
the wiring.
Fig. 4.1
CAUTION
• Install the indoor and outdoor units, cables
and wires at least 1m (3.2') from televisions
or radios to prevent static or image
distortion. Depending on the appliances,
a 1m (3.2') distance may not be sufficient.
• If the indoor unit is installed on metal,
it must be electrically grounded.
4
Display panel
Refrigerant connecting
pipe
Drain hose
