3 Product description
3.2 Abbreviations
DC
D.C.
Voltage rating
®
ABIPLAS WELD 150 CT 20
®
ABIPLAS WELD 250 CT 20
Tab. 10 Abbreviations

3.3 Signs and symbols used

Symbol Description
• Bullet symbol for instructions and lists

Cross reference symbol refers to detailed, supplementary or further information
1 Step(s) described in the text to be carried out in succession

3.4 Nameplate

1 Torch type
Fig. 1 Nameplate
EN - 8
Direct current
Duty cycle
Classification of the insulation resistance, voltage strength and
protection type
®
ABIPLAS
The following signs and symbols are used in the operating instructions:
The plasma welding torches are labelled as follows:
When making enquiries, please note the following information:
• Details of the certificate of conformity, serial number on the torch body,
torch type and size.
WELD welding torch with CT interface, 20° angle
2 Serial number
®
ABIPLAS WELD CT
1
2
