3. Layout, Connections & Jumper Settings
3.2 Connections
USB 2.0 B-Port:

4. Hardware Installation

Because there are large differences between PC's, we can give you only a general in-
stallation guide. Please refer your computer's reference manual whenever in doubt.
1. Connect the USB cable to the USB B-Port at the Hub.
2. Connect the optional power supply into the terminal block at the Hub.
3. Now connect the other end from the USB cable (A-Plug) to the A-Port at your PC.

5. Driver Installation

All Operating Systems

After the hardware installation the OS will recognize the device automatically and install
the drivers.
CHECK INSTALLED DRIVER
Open the >Device manager<. Now you should see at „USB-Controller" the following
new entry's:
If you see this or a similar information the device is installed correctly.
© Copyright 2018 by EXSYS Vertriebs GmbH. All Rights Reserved
USB 2.0 B-Port
Pin
Signal
1
VCC
2
DATA-
10
EX-1163HMS-WT
Pin
Signal
3
DATA+
4
GND
