3. Layout, Connections & Jumper Settings

3.1 Layout

Front Side:
4x USB 3.2 Gen 1
Downstream A-Port
Back Side:
Power LED
5V T-Block for optional
1x USB 3.2 Gen 1
Power Supply or to
Upstream Port
connect the EX-K1110

3.2 Connections

+5V T-Block:
ATTENTION!!!
Never connect power to GND, it will destroy
your Hardware!!!
GND (Ground)
+5V
