English EX-1181HMS
3. Layout, Connections & Jumper Settings

3.1 Layout

Front Side:
4x USB 3.2 Gen 1
Downstream A-Port
Back Side:
Power LED
7V-48V T-Block for 1x USB 3.2 Gen 1
optional Power Supply Upstream Port

3.2 Connections

+7V to +48V T-Block:
ATTENTION!!!
Never connect power to GND, it will destroy
your Hardware!!!
+7V to +48V GND (Ground)
