3. Layout, Connections & Jumper Settings

3.1 Layout

Front Side:
Power LED
7-48V T-Block for
optional Power Supply

3.2 Connections

+7V to +48V T-Block:
GND (Ground)
+7V - 48V
+7V to +48V DC-Connector:
© Copyright 2022 by EXSYS Vertriebs GmbH. All Rights Reserved
7-48V DC-Connector for
optional Power Supply
7x USB 3.2 Gen 1
Downstream C-Port
ATTENTION!!!
Never connect power to GND, it will destroy
your Hardware!!!
ATTENTION!!!
Never plug in with force!
10
EX-1147HMVS
1x USB 3.2 Gen 1
Upstream C-Port
