EX-1194HMS
3. Layout, Connections & Jumper Settings
3.1 Layout
7-48V T-Block for
optional external
Power Supply
3.2 Connections
+7V - 48V T-Block:
GND (Ground)
+7V - 48V
© Copyright 2018 by EXSYS Vertriebs GmbH. All Rights Reserved
1x USB 3.1 (Gen1)
Upstream B-Port
Power LED
ATTENTION!!!
Never connect power to GND, it will destroy
your Hardware!!!
3x USB 3.1 (Gen1)
Downstream A-Port
1x USB 3.1 (Gen1)
Downstream C-Port
11
English
