3. Layout, Connections & Jumper Settings

3.1 Layout

Front Side:
Power LED
Back Side:
3.2 Connections
+7V - 24V T-Block:
GND (Ground)
+7V - 24V
© Copyright 2021 by EXSYS Vertriebs GmbH. All Rights Reserved
7x USB 3.2 Gen 1
Downstream A-Port
1x USB 3.2 Gen 1
Upstream B-Port
ATTENTION!!!
Never connect power to GND, it will destroy
your Hardware!!!
7-24V T-Block for optional
external Power Supply
10
EX-1188HMS-3
7-24V DC Connector
for included external
Power Supply
