8.4) SAM-M-14-300N-268-145
Maximum contact force (symmetrical to mount)
Maximum contact stroke
Contact stroke generation
Contact stroke query
Maximum lever arm length
Maximum torque
Temperature range
8.5) SAM-P-50-068N-082-105
Maximum contact force (symmetrical to mount)
Maximum contact stroke
Contact stroke generation
Contact stroke query
Maximum lever arm length
Maximum torque
Temperature range
9)

Decommissioning

9.1) Storage
Do not store the side approach mechanism unprotected, outdoors or in a humid environment.
 Ambient temperature: -5 °C to +60 °C
 Atmospheric humidity: ≤ 85% (do not allow condensation to form!)
9.2) Disposal
The packaging material of the side approach mechanism is 100% recyclable.
The side approach mechanism contains the following materials:
 Steel
 Aluminium
 Brass
 Plastic and rubber
 Synthetic insulation material
Bring the side approach mechanism to a collection point suitable for recycling
electrical and electronic equipment, in accordance with the country-specific regulations.
33
©
INGUN: Subject to technical changes without notice. E&OE.
300 N
14 mm
manual
Micro switch (NO contact)
200 mm
3.0 Nm
-5 °C to +60 °C
68 N
50 mm
pneumatic
Proximity switch (optional)
120 mm
2.0 Nm
-5 °C to +60 °C
