English
Sample installation of SAM-H7-16-150N-020-060-S in
exchangeable kit ATS-MA11/S-5
©
INGUN: Subject to technical changes without notice. E&OE.
1) Pressure frame plate
(NHP)
2) Pressure bolt for stroke
control
3) Side approach
mechanism
4) Device under test (DUT)
5) Pressure plate (ADP)
6) Operating plunger
7) Probe plate (KTP)
8) Set screw for fine stroke
adjustment
20
