8. Specifications

FEATURES
• Input frequency: 10.7 - 12.75 GHz
• Polarization: Linear (vertical / horizontal)
• Antenna gain: 33 dBi @ 12.75 GHz
• LNB output: 1, 2 or 4
• LNB output frequency: 950 - 1.950 MHz / 1.100 - 2.150 MHz
• L.O. Frequency: 9.75 GHz / 10.6 GHz
• LNB gain: min. 55 dB / max. 66 dB
• Gain flatness: 5 dB
• Power supply: 12 - 14 V DC (V) / 16 - 19 V DC (H)
• Power consumption: max. 160 mA
• Operating temperature: -20° C - +60° C
• Storage temperature: -40° C - +80° C
OTHER
• Dimensions: 525 x 290 x 68 mm (without LNB)
• Dimensions: 525 x 290 x 145 mm (with LNB)
• Weight: 4.5 kg

Conformity information

Hereby, Megasat Werke GmbH declares that the following equipment complies
with the essential requirements and other relevant provisions of Directive EMV
2014/30/EU:
Flat antenna D1 Profi-Line (Art-No. 200210)
Flat antenna D2 Profi-Line (Art-No. 200211)
Flat antenna D4 Profi-Line (Art-No. 200212)
The declaration of conformity for these products is available at the company:
Megasat Werke GmbH
Industriestraße 4a
D-97618 Niederlauer
