3. Mounting options

3.3 Mounting on a wall

1
2
3
Hold the mounting plate A to the desired
mounting position on the wall and mark
the drilled holes.
Drill the four previously marked holes. Pay
attention to which dowels or screws you
use. Example: 8 mm dowels -> 8 mm drills
Mount the mounting arm to the moun-
ting plate A. To do this, insert the M6 x
55 mounting screws through the two
holes and fix them each with an M6 nut
on the opposite side.
11
