6. Skew setting

Signals in the vertical (red) and horizon-
tal (blue) line have an offset of exactly
90° to each other. Due to the different
position of the satellites, depending on
your location, it is possible that the sig-
nals do not meet exactly vertically and
horizontally on the LNB. To adjust this,
turn the LNB into the correct position to
the transmitted signal. This adjustment
to the LNB is called „skew adjustment".
The following figure shows the optimal setting of the LNB. More accurate the
match, the better of reception.
bad
reception
Country City
Bulgaria Sofia
Denmark Copenhagen
Finland Helsinki
France Paris
Germany Berlin
England London
Greece Athens
Hungary Budapest
Italy Rome
Poland Warsaw
Portugal Lisbon
Spain Madrid
Belgium Brussels
Sweden Stockholm
Switzerland Bern
Austria Vienna
good
reception
Astra 2 Astra 3 Astra 1
+1.7 +6.8
-3.4 -0.4
+5.2 +7.9
-13.9 -10.5
-4.1 -0.7
-13.7 -10.7
+1.3 +7.3
-1.3 +3.0
-9.8 -5.0
+1.5 +5.1
-30.2 -27.0
-24.8 -21.2
-11.2 -7.9
+1.1 +3.8
-11.3 -7.5
-3.4 +0.7
best
reception
Hotbird Astra 4
+11.4 +11.0 +19.0
+2.5 -0.3
+10.3 +6.8 +11.2
-7.2 -9.2
+2.6 +0.3
-7.8 -10.3
+12.7 +13.4 +22.5
+6.9 +5.6 +12.8
-0.4 -0.6
+8.4 +6.1 +12.2
-23.7 -25.3
-17.6 -18.7
-4.8 -7.0
+6.4 +3.0
-3.8 -5.2
+4.5 +3.0 +10.2
LNB position
Satellite signal
Thor Hispasat
+24.0 +41.0
+5.3 +9.1 +24.8
+14.2 +25.2
-2.2 +2.9 +25.0
+6.6 +10.8 +27.8
-4.0 +0.6 +21.6
+28.1 +45.9
+17.5 +34.7
+8.5 +14.6 +37.0
+16.2 +31.0
-16.8 -10.1 +23.9
-9.9 -3.2 +27.5
-0.3 +4.4 +24.7
+7.8 +11.0 +23.8
+2.4 +7.8 +29.5
+15.0 +32.9
Eutelsat 5
+27.2
+11.6
+16.0
+6.3
+13.5
+3.9
+31.6
+20.5
+18.5
+18.8
-5.1
+1.5
+9.3
+13.0
+11.4
+18.0
