3. Mounting options

3.4 Mounting on a window

1
2
3
12
Mount the window holder A to the
mounting arm. Use two screws
M6 x 10 for this purpose.
Mount the window holder B to the
mounting arm. Use two screws
M6 x 10 for this purpose.
Hang the antenna with the window
holder A in the fold of the window. The
window holder B serves as a support.
You can adjust the distance from the
window to the outside wall with the two
fixing screws M6 x 10 on the window
holder A. The mounting arm should
generally be mounted horizontally.
