Detailed drawing

Art. no. Designation
Item
1 68 42 36 Gun head housing
2 68 42 37 Air valve seal
3 68 42 38 Needle guide
7 68 42 39 Nut packet
8 68 42 17 Needle packet set
9 68 42 12 Air cap
10 68 42 14 Air cap spigot nut
12 68 42 19 Air valve
13 68 42 21 Trigger
14 68 42 23 Bolt to attach the trigger
15 68 42 24 Nut to attach the trigger
17 68 42 26 Needle plug
19 68 42 27 Spring
21 68 42 28 Adapter to connect the
siphon cup
22 68 42 06 Complete siphon cup with
lid
22a 68 42 07 Siphon cup seal
Translation of the original instruction
Art. no.
Quantity Item
1 22b 68 42 09 Siphon cup
1 23 68 42 29 Air pipe handle
1 24 68 42 31
1
25 68 42 32 Air hose connection
1
29 68 42 16
1
32 68 42 33 Air valve plug
1
37 68 42 11
1
44a 68 42 08 Nozzle/needle, 0.8 mm
1
44b 68 42 13
1
44c 68 42 18
1
44d 68 42 22 Nozzle/needle, 2.2 mm
1
44e 68 42 25 Nozzle/needle, 2.5 mm
1
45 68 42 34 Air hose connecting nipple
1
1
1
118
Designation
Gun handle
Complete non-return valve
Filter screen
Nozzle/needle, 1.3 mm
Nozzle/needle, 1.8 mm
Quantity
1
1
1
1
1
1
1
1
