Maintenance
The spraying device features lifetime lubrication. The only
required maintenance measures are cleaning and repla-
cing the filter.
Filter cartridge
The spraying device filter must be clean to guarantee an
adequate air flow to cool the motor and atomise the sub-
stance.
The spraying device features an air filter display on the
front panel. The indicator lamp lights up if the filter is
clogged or the air flow rate is too low.
Cleaning the filter
1.
Switch off the spraying device and disconnect the mains
plug.
2.
Undo the four screws (18) and remove the filter bracket
(17) and pre-filter (20).
3.
Remove the main filter (21) and clean using one of the
following methods:
Carefully tap the filter on a flat surface with the dirty side
facing downwards.
Blow compressed air through the filter plate in the oppo-
site direction of the arrows on the filter side (from the cle-
an to the dirty side).
Soak the filter for 15 minutes in water and a mild clea-
ning agent. Rinse the filter until it is clean. Dry the filter
in ambient air.
Do not insert a humid filter into the turbine to prevent the
risk of electric shocks. Installing a humid filter into the
spraying device may also damage the turbine.
