C. THE HELMET
2. Remove the cheek pad by pulling
the three snaps out of the red
plugs and sockets.
3. Unzip the zipper.
4. Thread the chinstrap out of
the A.R.O.S. strap and pull this
sideways. Pull the neck strap
rearwards out of the cheek pad.
5. Repeat points 1 to 4 to dismantle
the cheek pad on the other side.
80
Mounting the cheek pad
1. Push the A.R.O.S. strap through
the neck strap channel as far as
the chinstrap padding opening.
2. From the outside, thread the
chinstrap through the cheek
cushion and through the A.R.O.S.
strap and pull it tight from the
back.
3. Zip up the zipper.
81
