Para- Parameter name Parameter description
meter
S1.6 DIGITAL INPUT This setting defines controller operation mode if short circuit is detected on
T1, T6, T8 input T1, T6 or T8.
1- Day temperature operation mode, regardless to currently selected opera-
tion mode. See also parameter S1.9.
2- Additional direct circuit is connected. Temperature requirements of
additional direct circuit (P3.5 and P3.6) are also considered for calculation
of requested boiler temperature. By schemes with two heat sources the
switchover to other heat source is done with delay, set with parameter
S5.15.
3- Additional direct circuit is connected. Temperature requirements of
additional direct circuit (P3.5 and P3.6) are also considered for calculation
of requested boiler temperature. By schemes with two heat sources the
switchover to other heat source is done without delay.
4- Switchover from heating to cooling operation mode.
5- Boost heating function is activated. This setting disables regular boost
heating function which is activated by changeover from night to day tempe-
rature period.
6- Liquid fuel boiler is blocked. Controller will operate only with solid fuel
boiler.
7- Counter for boiler operation time.
S1.7 ANTI-BLOCK All outputs that haven't been activated in the last week are activated on
FUNCTION Friday between 20:00 and 20:15. for 60 seconds.
S1.8 REMOTE ACTI- Selection if remote activation can be activated only local or also from
VATION VIA BUS master controller.
S1.9 CIRCUITS FOR Selection of circuits affected by remote activation.
REMOTE ACTI-
VATION
S1.10 BUILDING TYPE Selection of building type (time constant). For heavy (thick walls ) and good
isolated buildings select higher value. For light (thin walls, no heat accumu-
(TIME CON-
STANT) lation) and poor isolated objects select lower value.
S1.13 SENSOR T1
Correction of displayed measured temperature for sensor T1.
CALIBRATION
S1.14 SENSOR T2
Correction of displayed measured temperature for sensor T2.
CALIBRATION
S1.15 SENSOR T3
Correction of displayed measured temperature for sensor T3.
CALIBRATION
S1.16 SENSOR T4
Correction of displayed measured temperature for sensor T4.
CALIBRATION
S1.17 SENSOR T5
Correction of displayed measured temperature for sensor T5.
CALIBRATION
S1.18 SENSOR T6 Correction of displayed measured temperature for sensor T6.
CALIBRATION
S1.19 SENSOR T7 Correction of displayed measured temperature for sensor T7.
CALIBRATION
S1.20 SENSOR T8 Correction of displayed measured temperature for sensor T8.
CALIBRATION
41
Setting range Default
setting
1- REMOTE ACTIV. 1
2- DIR. CIRC.,
DELAYED
SWITCHOVER
3- DIR. CIRCUIT
4- COOLING
5- BOOST
6- BOILER LOC-
KOUT
7- BURNER COUN-
TER
0- NO 0
1- YES
1- LOCALY 2
2- LOCALY & FROM
MASTER
1- CIRCUIT 1 3
2- CIRCUIT 2
3- CIRCUIT 1 & 2
0 ÷ 12 h 0
0
-5 ÷ 5 K
0
-5 ÷ 5 K
0
-5 ÷ 5 K
0
-5 ÷ 5 K
-5 ÷ 5 K 0
-5 ÷ 5 K 0
-5 ÷ 5 K 0
-5 ÷ 5 K 0
