STEP 2 - SET HYDRAULIC SHEME
Later you can change the selected hydraulic scheme with service parameter S1.1.
3. STEP- SET THE HEATING CURVE STEEPNESS FOR THE FIRST CIRCUIT
Later you can change the heating curve steepness with parameter P2.1.
The meaning of heating curve steepness is described in detail on page 36.
User manual
Select a hydraulic scheme for controller operation.
Move between schemes with buttons
Confirm the selected scheme by pressing
All schemes with mixing heating circuit are
available for radiators and floor/wall heating.
The controller requires a confirmation of language selec-
tion with the button.
In case you choose the wrong scheme, return to scheme
selection with the
Set the heating curve steepness for room heating for the
first heating circuit.
Change the value with buttons
Confirm the selected value by pressing
The controller requires a confirmation of the set heating
curve steepness with the
In case you choose the wrong heating curve steepness,
return to heating curve steepness selection with the
button.
10
button.
and
.
button.
and .
.
.
