DESCRIPTION OF SYMBOLS PRESENTED ON THE DISPLAY

SYMBOLS FOR HEATING CIRCUITS
Symbol Description
The first - mixing heating circuit.
The second - direct or mixing heating circuit.
D. h. w. warming.
SYMBOLS FOR OPERATION MODE INDICATION
Symbol Description
Room heating.
Room cooling.
Operation according to program interval - day temperature. *
Operation according to program interval - night temperature. *
Desired day temperature operating mode.
Desired night temperature operating mode.
D. h. w. warming according to program interval - switch-on interval. *
D. h. w. warming according to program interval - switch-off interval. *
Switch off.
Permanent switch-on of d. h. w. warming.
Manual operation mode.
Chimney sweep - emission measurement.

SYMBOLS FOR USER FUNCTIONS

Symbol
Description
»PARTY« mode activated.
»ECO« mode activated.
Holiday mode activated.
One-time d. h. w. warming activated.
Anti legionella protection activated.
*
The number inicates the first or the second time program accordingly.
13 User manual
